Which Charging Device is
Better Suited to You
Infinity S 3.5KW
220×95×57.5mm【H*W*D】
Control Box Material
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 2.1KG
Net Weight
PVC+Copper-aluminium alloy
Cable Material
3*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type1, Type2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Interface
Infinity Pro 3.5KW
220×95×57.5mm【H*W*D】
Control Box Material
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 2.1KG
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type1, Type2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE A+6
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Interface
Infinity S 7KW
220×95×57.5mm【H*W*D】
Control Box Material
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 3.7KG
Net Weight
PVC+Copper-aluminium alloy
Cable Material
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
7KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A-20A-24A-32A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type1, Type2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
CEE Stecker
Interface
Infinity Pro 7KW
220×95×57.5mm【H*W*D】
Control Box Material
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 3.7KG
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
7KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A-20A-24A-32A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type1, Type2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
CEE Stecker
Interface
Panda S 3.5KW
220×95×57.5mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
About 2.1KG
Net Weight
PVC+Copper-aluminium alloy
Cable Rating
3*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Temperature
IP66
Protection Class
Type1, Type2, GB/T 20234
Protection Class
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
Panda Pro 3.5KW
220×95×57.5mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
About 2.1KG
Net Weight
TPU+Copper-aluminium alloy
Cable Rating
3*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Temperature
IP66
Protection Class
Type1, Type2, GB/T 20234
Protection Class
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
Panda S 7KW
220×95×57.5mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
About 3.5KG
Net Weight
PVC+Copper-aluminium alloy
Cable Rating
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
7KW
Max Power
AC80V-260V
Output Voltage
8A-10A-13A-16A-20A-24A-32A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Temperature
IP66
Protection Class
Type1, Type2, GB/T 20234
Protection Class
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
Panda Pro 7KW
220×95×57.5mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
About 3.5KG
Net Weight
TPU+Copper-aluminium alloy
Cable Rating
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
7KW
Max Power
AC80V-260V
Output Voltage
8A-10A-13A-16A-20A-24A-32A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Temperature
IP66
Protection Class
Type1, Type2, GB/T 20234
Protection Class
UL94 V0
Flammability rating
RCD TYPE A
Leakage Protection Level
CE, RoHS, FC
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
AquaPro 3.5KW
178*83*45mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 2.1KG
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*2.5mm²+0.75mm²
Cable Size
6M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type 2
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, TUV
Certificate
LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
SmoothPro 3.5KW
210*101*75mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 2.1KG
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP66
Protection Class
Type 2
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, TUV
Certificate
Display Screen, LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP66
Waterproof grade
SmoothPro 7KW
210*101*75mm【H*W*D】
Control Box Size
PC+ASA
Control Box Material
PC+ASA
Gun Material
About 3.5KG
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
3.5KW
Max Power
AC 80V-260V
Output Voltage
8A-10A-13A-16A-20A-24A-32A
Output Current
3W
Standby Power
5％~95％(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
＜2000M
Work Altitude
IP65
Protection Class
Type 2
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, TUV
Certificate
Display Screen, LCD Indicator Light
Interface
EU Plug, US Plug or Customizable
Plug
IP65
Waterproof grade
SpeedyPro7KW
355mmx225mmx125mm【H*W*D】
Size
Wall-Mounted/Column
Installation Method
PC+ASA
Control Box Material
PC+ASA
Gun Material
5.5kg
Net Weight
TPU+Copper-aluminium alloy
Cable Material
3*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 80V-260V
Input Voltage
50Hz/60Hz
Input Frequency
7KW
Max Power
AC 80V-260V
Output Voltage
Single Phase
Output Current
3W
Standby Power
5%~95%(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
<2000M
Work Altitude
IP65
Protection Class
Type 1, Type 2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, RoHS , FC, TUV
Certificate
LCD Display Screen
Interface
SpeedyPro 11KW
355mmx225mmx125mm【H*W*D】
Size
Wall-Mounted/Column
Installation Method
PC+ASA
Control Box Material
PC+ASA
Gun Material
7kg
Net Weight
TPU+Copper-aluminium alloy
Cable Material
5*2.5mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 380V
Input Voltage
50Hz/60Hz
Input Frequency
11KW
Max Power
AC 380V
Output Voltage
Three Phase
Output Current
3W
Standby Power
5%~95%(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
<2000M
Work Altitude
IP65
Protection Class
Type 1, Type 2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, RoHS , FC, TUV
Certificate
LCD Display Screen
Interface
SpeedyPro 22KW
355mmx225mmx125mm【H*W*D】
Size
Wall-Mounted/Column
Installation Method
PC+ASA
Control Box Material
PC+ASA
Gun Material
7kg
Net Weight
TPU+Copper-aluminium alloy
Cable Material
5*6mm²+0.75mm²
Cable Size
5M or Customizable
Cable Length
AC 380V
Input Voltage
50Hz/60Hz
Input Frequency
22KW
Max Power
AC 380V
Output Voltage
Three Phase
Output Current
3W
Standby Power
5%~95%(non-condensing)
Work Humidity
-30℃~+50℃
Work Temperature
<2000M
Work Altitude
IP65
Protection Class
Type 1, Type 2, GB/T
Standard
UL94 V0
Flammability rating
RCD TYPE B
Leakage Protection Level
CE, RoHS , FC, TUV
Certificate
LCD Display Screen
Interface
